Wrapped Bronze Bearing for Motor  Tractors and Trucks

Wrapped Bronze Bearing for Motor  Tractors and Trucks

Wrapped Bronze Bearing for Motor Tractors and Trucks TCB905 is improved from product TCB900.The special solid lubricant

Send your inquiry

DESCRIPTION

Basic Info
Model NO. TCB905
Universal Yes
Type Bushing
Material CuSn8P+Graphite
Sample Available
Processing Cold Extrusion
Other Type Sleeve/Washer/Flanged
Transport Package Anti-Rust Paper, Carton, Wood Case or Pallet
Specification customized
Trademark TEHCO
Origin China
HS Code 8483300090
Production Capacity 100000.0 Piece/Pieces Per Month
Product Description
Wrapped Bronze Bearing for Motor Tractors and Trucks

TCB905 is improved from product TCB900.The special solid lubricant is imbedded into diamond oil sockets on surface.It has very low friction coefficient and good wear-resistance.It is used to the condition of no or little oil.

Technical Data

Performance IndexData
MaterialCuSn8P(Qsn8-0.3)
Density g/cm?8.8
Max Dynamic Load N/mm?100
Max Linear Velocity(Grease) m/s2.5
Max PV value Grease N/mm?·m/s2.8
Pressure strength N/mm?>460
Yield Strength N/mm?>280
Hardness90~150
Mating AxisHardness≥50
Roughness0.4~1.0
Working Temperature ºC-40~150
Friction Coefficient0.06~0.1
coefficient of heat conduction W/m·K58
Linear expansion coefficient18.5×10-6/K
Typical applicationApplication:hoisting, mining machinery,forest machinery, agricultural machinery etc.
We can also develop according to customers special request while out of this table

Packing & delivery

Our Factory&Company

Wrapped Bronze Bearing for Motor Tractors and Trucks

Wrapped Bronze Bearing for Motor Tractors and Trucks



Q: Are you trading company or manufacturer?A :Our management is focused on exporting activities for more than ten years and we have our own bushing factory
Q: How to ensure the quality?
A:We produce as per the confirmed technology or drawings for each customer. And our factory has a strict quality control system.If the products is damaged due to our reasons,we assume full responsibilities
Q: What is your delivery time?A :Generally 10-25 days after order. It depends on the quantityQ: Do you produce samples? Is it free or extra?A :For standard products, we produce samples free of charge for our customers. And the express costs will be burdened by the customer, but can be returned after the order is placed.
